Printing mode heat transfer/heat transfer
Resolution 300 dpi (12 dot/mm)
Printing speed can reach 4 ips (102mm/SEC)
Print width 4.16 inch (105.7 mm)
The minimum length of print is 0.16 inch (4mm) * * *; Maximum 73.19 "(1859 mm)
Processor 32-bit RISC CPU
Memory Flash 128 MB Flash (the user has a capacity of 60 MB)
SDRAM 32 MB
Sensor form reflector: portable left aligned
Penetration sensor: portable left aligned
The label length can be automatically detected or manually controlled by means of continuous paper, spacing label paper, black line marking paper or punch paper
The width of the
Tear paper: minimum 1 inch (25.4 mm) - the maximum 4.64 "(118 mm)
Cut: 4.61 inches (117 mm)
Peeling machine/recoil: 4.64 inches (118 mm)
The minimum thickness is 0.003 inch (0.076 mm) - the maximum 0.01 inch (0.25 mm)
Paper roll diameter
The maximum 8 "(203.2mm) 3 inch core (76.2 mm)
Maximum 6 "(152.4 mm) 1.5 inch core (38.1mm)
Maximum 5 "(127mm) 1 inch core (25.4mm)
The paper scrolls are as low as 1 inch (25.4 mm) - the maximum 3 "(76.2 mm)
The carbon belt specification is usually waxy, mixed and anti-scrape resin
The maximum length is 1476 feet (450 meters).
The minimum width is 1.18 inches (30 mm) - the maximum of 4.33 inches (110 mm)
Maximum outer diameter of 3 inches (76.2 mm)
Carbon shaft 1 inch (25.4mm)
The program language, EZPL, GEPL, GZPL can automatically switch
GoLabel (limited to EZPL)
Drivers Windows 2000, XP, Vista, Windows 7, 8.1 and 10, Windows Server 2003 & 2008, MAC, Linux
DLL Win CE,.net, Android, Windows Mobile, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1 / Windows 10
Built-in Bitmap Fronts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90 °, 90 °, 180 ° rotatable, single characters, 90 °, 180 °, 270 ° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
The vera.ttf Fonts (Bold Italic/Underline). 0 ° and 90 °, 180 °, 270 ° rotatable
Download a font Bitmap fonts 90 °, 180 °, 270 ° rotatable, single characters, 90 °, 180 °, 270 ° rotatable
Asian fonts 16 x16, 24 x24. Traditional Chinese (BIG - 5), Simplified Chinese (GB2312), Japanese (S - JIS), Korean (KS - X1001) 90 °, 180 °, 270 ° rotatable and 8 times expandable in horizontal and vertical directions
Vector Fonts the vera.ttf Fonts (Bold Italic/Underline). 0 ° and 90 °, 180 °, 270 ° rotatable
Bar code one-dimensional bar code
China Postal Code, Codabar, Code 11, Code 32,Code 39, Code 93, Code 128 (subset A, B, C), EAN-8, EAN-13, EAN-8/13 (with 2 & 5 digits extension), EAN 128, FIM, German Post Code, GS1 DataBar, HIBC, Industrial 2 of 5 , Interleaved 2-of-5 (I 2 of 5), Interleaved 2- o-f 5 with Shipping Bearer Bars, ISBT – 128, ITF 14, Japanese Postnet, Logmars, MSI, Postnet, Plessey, Planet 11 & 13 digit, RPS 128, Random Weight, Standard 2 of 5, Telepen, UPC-A, UPC-E, UPC-A and UPC-E with EAN 2 or 5 digit extension, UCC 128, UCC/EAN-128 K-Mart
Two dimensional barcode
Aztec code, code 49, Codablock F, Datamatrix code, MaxiCode, Micro PDF417, Micro QR code, PDF417, QR code, TLC 39
Codepage 437, 737,850, 851, 852, 855, 857, 860, 861, 862, 863, 863, 865, 865, 865, 869, Windows 1250, 1251, 1252, 1253, 1254, 1254, 1255, 1255, 1255, 1255, 1255, 1255, 1255, 1257
Unicode UTF8, UTF16BE, UTF16LE
Graphics processing supports monochrome PCX, BMP graphics format; Other graphics formats can be downloaded by software
Communication interface USB 2.0 connection port (b-type)
USB Host (A - Type)
RS - 232 serial port (DB - 9)
10/100 MBPS front-end ports
Control panel color LCD display and operation key
A set of multifunctional hardware control keys: feeds
Power supply/key
Paper detection key
Power supply 100-240v AC, 50-60hz (dc automatic switching power supply generator)
The timing device standard is fitted
Working environment temperature operation 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature - 4 ° F to 140 ° F (20 ° to 60 ° C - C)
Humidity operating humidity 20-85%, non-condensing sing
Storage humidity 10-90%, non-condensing
The safety regulations CE (EMC), FCC Class B, CB, UL, cUL, CCC
Body size 15.86 inches (403 mm)
Height 10.79 "(274 mm)
Width 10.24 "(260 mm)
The body weighs 23.81 pounds (10.8 kg) without any other materials or options.
The selection of project shaper
The cutting
Parallel port transmission interface
External forward/backward reels
The bluetooth module
WiFi module
