Printing mode heat transfer/heat transfer
Resolution 203 dpi (8 dots/mm)
Print speed 5 IPS (127 mm/s) * *
Print width 108 mm (4.25)
Printing length is 4 mm (0.16) * *;
The greatest number is 1727 mm (68 ")
Processor 32-bit high-performance microprocessors
Memory 128 MB Flash (the user can have 60 MB)
32 MB SDRMS
Sensor form reflective sensor: portable
Permeable sensor: fixed set
The label length can be automatically detected or manually controlled by means of continuous paper, spacing label, black label or punch label
Minimum 25.4 mm (1) ~ 118mm (4.64)
Minimum 0.06 mm (0.0024) ~ the maximum 0.25 mm (0.01 ")
Maximum diameter 152 mm (6 ")
25.4 mm (1), 38.1 mm (1.5 "), 76.2 mm (3)
The carbon belt specification is the type of waxy base type, mixed type, anti-drag resin type
300 m (981)"
Minimum 30 mm (1.18) ~ 110mm (4.33)
68 mm (2.67 ")
25.4 mm (1 ")
The program language, EZPL, GEPL, GZPL, can be automatically switched
Random software GoLabel (only EZPL)
Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1
Win CE,.net, Android, Windows Mobile, Windows 2000 / XP/VISTA/Windows 7 / Windows 8.1
The built-in font Bitmap font 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 90 °, 90 °, 180 ° rotatable, single characters, 90 °, 180 °, 270 ° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Vector Fonts the vera.ttf Fonts (Bold Italic/Underline). 0 ° and 90 °, 180 °, 270 ° rotatable
Download the font to print direction rotating Angle is 90 °, 180 °, 270 °, the font can separate rotation Angle is 90 °, 90 °, and 270 °
16x16, 24x24. Traditional Chinese (big-5), Simplified Chinese (GB2312), Japanese (s-jis), Korean (ks-x1001)
Asia downloadable fonts, print direction rotating Angle is 90 °, 180 °, 180 °, and can be horizontal or vertical 8 x magnification font can separate rotation Angle is 90 °, 90 °, and 270 °
Print direction rotating Angle is 90 °, 180 °, and 270 °, fonts can be separate rotation Angle is 90 °, 180 °, and 270 °
8/13 barcodes Code 39, 93, EAN Code (add on 2 & 5), UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset of A, B, C), 128, 128, 128, UCC RPS EAN UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, 2 of 5, Industrial Standard, 2 of 5, Logmars, Code 11, Code 49, and Cadablock
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, and Aztec code.
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 869, 869, 869, 869, and 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, and 1257
Unicode UTF8, UTF16BE, UTF16LE
The graphics processing default supports monochrome PCX, BMP, and other image file formats can be supported by software
Communication interface USB 2.0 port (b-type)
Tag detection key
Control panel two double-color LED light: Ready, Status
A set of multifunctional hardware control keys: FEED keys
Power supply/key
Power 100-240 V AC, 50-60Hz (dc automatic switching power supply)
Work environment the work environment operating temperature 41 ° F to 104 ° F (5 ° ~ 40 ° C) C
Storage temperature - 4 ° F to 122 ° F (20 ° ~ 50 ° C - C)
Humidity 30 percent to 85 percent, not condensation
10 percent to 90 percent, not condensation
EMC, FCC Class A, UL, cUL, CB, CCC, BIS
Body size 320 mm (12.5 ")
Height 220 mm (8.7)
Width 275 mm (10.8)
The body's weight is not contained in any other consuming materials or is equipped with a weight of 7.7 kg (16.98 LBS).
Select the knife of the purchase item
Automatic stripper
The external paper holder (the maximum size of the paper volume is 250 mm / 10)
WIFI module (distributor installation)
Please consult the original purchase unit for the purchase item. The above specifications are subject to actual shipment, subject to actual shipment. All trademarks listed above are owned by the original company.
In response to different consumables, the actual printing size and printing speed must be determined by the actual consumables.
