Printing mode heat transfer/heat transfer
Resolution 300 dpi (12 dots/mm)
Printing speed 4 IPS (127 mm/s)
Print width 4.16 "(105.7 mm)
Print length Min. 0.16 (4 mm) * * * *; Max. 30 "(762 mm)
Memory 8 MB Flash (user available capacity is 4 MB)/SDRAM 16MB
Sensor form reflector: mobile
Permeable sensor: medium fixed type (dual sensor)
Paper type: continuous paper, spacing label paper, black line marker paper or punch paper, and the label length can be detected automatically or manually
The action command is mandatory
Paper width: 25.4 mm (1 inch) ~ 118 mm (4.64 inch)
Paper thickness: 0.06 mm (0.003 inch) ~ 0.25 mm (0.01 inch)
Outside diameter: 127 mm (5 ") diameter
Paper reel core: 25.4 mm (1 inch) / 38.1 mm (1.5 inch) / 76.2 mm (3 ")
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 300 m (981 feet)
Width: 30 mm to 110 mm (1.18 inches to 4.33 inches)
Maximum size: 68 mm (2.67 inches)
Shaft core: 25.4 mm (1 inch)
Program language EZPL
Random software label typesetting software: qlab-iv (supporting only EZPL)
Driver: Windows 2000, XP, Vista, 7, Windows Server 2003 & 2008
DLL: Windows 2000, XP and Vista
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Print direction can be rotation Angle for 0 ° and 90 °, 180 °, 270 °, the font can be single rotation Angle for 0 ° and 90 °, 180 °, 270 °, and can be horizontal or vertical amplifier 8 times
Vector fonts: rotating Angle of 0 °, 90 °, 180 °, 270 °
Download a font Bitmap fonts: Bitmap fonts, downloadable print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °, fonts can be
Single rotation Angle for 0 ° and 90 °, 180 °, 270 °, and can be horizontal or vertical amplifier 8 times
Asian fonts: Asia downloadable fonts, print direction can be rotation Angle for 0 ° and 90 °, 180 °, 270 °, and can be horizontal or
Vertical amplification eight times
Vector fonts: downloadable vector fonts (scalable the font), print direction can rotation Angle for 0 °, 90 °, 180 °, 270 °
Bar code 1 - D Bar codes
Code 39, the Code 93, 8/13 (add on 2 & 5) EAN, UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), 128, EAN RPS 128, 128, UCC UCC/EAN - 128 - K Mart, the Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar
2-d Bar codes
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
Codepage 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
Windows 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8, UTF16
The graphics processing preset supports monochrome PCX, BMP, and other diagram types can be supported by software control
Communication interface USB/Parallel
USB/Serial/Ethernet
Control panel two double-color LED light: Ready, Status
A set of multifunctional hardware control keys: feeds
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing
Storage humidity: 10-90%, non-condensing
(EMC), FCC Class A, CB, cUL, CCC
Length of body: 285 mm (11.2 ")
Height: 171 mm (6.8 inches)
Width: 226 mm (8.9 inch)
The body weight of the body does not contain other consumables or choose and choose to be equipped with weight of 2.72 kilograms (6 pounds)
Select the knife of the purchase item
Automatic stripper
External paper holder (the maximum paper diameter is 10 inches)
External forward/backward reels
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
* * in response to different consumption characteristics, the actual printing size should be based on actual consumption.
