Printing mode heat transfer/heat transfer
Resolution 300 dpi (12 dots/mm)
Printing speed 5 IPS (102 mm/s)
Print width 105.7 mm (4.16 inches)
Print length printing length is 4 mm (0.16 ") * *; the printing length is 762 mm (30).
Memory 8MB Flash (user capacity is 4MB); 16 MB SDRAM
Sensor form fixed reflection sensor; In the rear
Penetration sensor
Paper type: continuous paper, label paper, black line marking paper or punch paper, and the label length can be automatically detected or manually controlled
Paper width: 25.4 mm (1 ") ~ 118 mm (4.46 ")
Paper thickness: 0.06 mm (0.003-inch) ~ 0.2 mm (0.01 inch)
Outside diameter: 127 mm (5 ") diameter
Paper roll core: 25.4 mm (1 inch) / 38.1 mm (1.5 inch)
Carbon belt specifications: the type of waxy, mixed, and anti-scrape resin
Length: 300 m (981 feet)
Width: 30 mm to 110 mm (1.18 inches to 4.33 inches)
Maximum size: 68 mm (2.67 inches)
Shaft core: 25.4 mm (1 inch)
The program language, EZPL, GEPL. Can automatically switch
Random software volume typesetting software: GoLabel (supporting EZPL only)
Driver: supports Windows 2000, XP, Vista, 7, and Windows Server 2003 & 2008
DLL: supports Windows 2000, XP and Vista
Built-in Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap font print direction rotating Angle is 90 °, 180 °, 270 °, the font can separate rotation Angle is 90 °, 180 °, 270 °
Bitmap fonts can be magnified eight times horizontally or vertically
Vector fonts (scalable font), rotating Angle is 90 °, 180 °, 270 °
Download the font Bitmap fonts, downloadable print direction can rotate Angle is 90 °, 180 °, 270 °. Be separate font rotation Angle is 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Asia downloadable fonts, print direction rotating Angle is 90 °, 180 °, 270 °, can be horizontal or vertical amplifier 8 times
Downloadable vector fonts (scalable font), the print direction rotating Angle is 90 °, 180 °, 270 °
Bar code 1 - D Bar codes:
Code 39, 93, EAN Code (add 8/13 on 2 & 5), UPC A/E (add on 2 & 5), the I 2 of 5 & I 2 of 5 with Shipping Bearer Bars,
Codabar, Code 128 (subset of A, B, C), 128, 128, 128, UCC RPS EAN UCC/EAN - 128 - K Mart, the Random Weight,
Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, and GS1 DataBar
2-d Bar codes:
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code, and Aztec code
CODEPAGE 437, 850, 851, 852, 855, 857, 861, 862, 863, 865, 866, 869, 869, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255,1257
Unicode (UTF8, UTF16)
Graphics processing supports monochrome PCX, BMP, and other diagram file types can be supported by software control
Communication interface USB2.0 port
The rs-232 (db-9) serial port
10/100 MBPS Ethernet networks
USB Host
Control panel color LCD display and operation key
A set of multifunctional hardware control keys: feeds
Power supply/key
The paper detects key
The timing device is built in standard
Power supply 100-240vac, 50-60hz (dc automatic switching power supply generator)
Working environment temperature operation: 41 ° F to 104 ° F (5 ° C to 40 ° C)
Storage temperature: - 4 ° F to 122 ° F (20 ° C to 50 ° C) -
Humidity: 30-85%, non-condensing.
Storage humidity: 10-90%, non-condensing.
(EMC), FCC Class A, CB, CCC, cUL
Body size: 280 mm (11 ")
Height: 186 mm (7.3 inches)
Width: 210 mm (8.3 inches)
The body weight of the body does not contain other consumables or choose and choose to be equipped with weight of 2.72 kilograms (6 pounds)
Select the knife of the purchase item
Automatic stripping paper
External paper holder (250mm / 10 diameter)
External forward/backward reels
Please refer to the original purchasing unit. The above specifications are subject to change without prior notice. All trademarks listed above are owned by the original company.
The actual printing size and printing speed should be determined according to the actual consumables.
